How To Use A PCB Calculator

Views: 470 Author: Site Editor Publish Time: 2022-09-13 Origin: Site

Are you aware that to keep your printed circuit board from being damaged, you must choose the trace width?

Do you agree that the breadth of your trace affects how much current it can carry? You should be aware of such things as a PCB enthusiast if you want your PCB manufacturing efforts to be successful.

If you don't adhere to the stated criteria, you could wind up building a PCB that is occasionally inoperable or useless. Fortunately, we have written this article to help you know how to use the PCB trace width calculator to determine your PCB trace width.

What exactly is a PCB trace width calculator?

A PCB trace width calculator is a tool that uses IPC 2221 formulae to calculate PCB trace width. When designing a circuit board, you must keep the trace width very much in mind.

You should give shreds the proper breadth to protect them from damage brought by high temperatures. The best course of action would be to design your PCB traces to withstand a maximum current load before failing.

As you conduct more current via a route, keep in mind that heat is produced. As a result, the trace burns out or damages the circuit board laminate when the current load surpasses the higher limit. This may cause irreparable PCB damage. ​


​How to Calculate Trace Width Using a PCB Trace Width Calculator ​

Some parameters must be imputed for this calculator to determine the necessary width of the trace. This width is represented in mils and involves the use of a few different values. These consist of:

· The square area of the conductive layer is typically expressed in mils. '

· The weight of the trace is expressed in ounces per square foot.

What makes the External and Internal PCB Trace Width Calculators different from one another?

Calculators that determine the necessary width of an internal PCB trace are available. This internal trace width was chosen to support carrying a particular current quantity.

Calculators that determine the width of an external PCB trace are comparable tools. The trace width result is also helpful for the transmission of a specific quantity of current. As a result, their placement accounts for the discrepancy between the exterior and interior traces. This area is connected to the board's substrate.

​Why Is It Important to Use a PCB Trace Width Calculator?

1. The correct current conductance is ensured by using your PCB trace width calculator.

2. You may determine the width of your trace by using this circuit calculator with the maximum current rating you want.

3. The temperature increase that your PCB records are up to your control. You may do this by using your PCB trace width calculator.

Purchase high-quality, high-precision, and high-density PCBs from us today!

If you're seeking high-quality Flex PCBs, 1-16L layer Rigid PCBs, High-Frequency PCBs, HDI PCBs, and Metal Base Aluminium PCBs to meet your diverse demands. VictoryPCB is the company for you.​To contact us or learn more about the PCB for you, please click here.
