Monthy Capability: 2500 Sq M/Month
Layer: 1 Layers
Material: Aluminum based
Dimension: 385*175.5mm
Finished board thickness: 2.0mm
Finished copper thickness: 2oz
Thermal conductivity:3W/MK
A Professional PCB Manufacturer since 2005
Small and Middle/Large batches, Multiple Varities, Short Lead Time
Certificated with UL (E315391), ISO 14001, IATF16949, ISO 9001, SGS, ISO13485, SA8000
Capablity 60,000Sqm/3000PNs per month, 500staffs
Make oversized board (reach to 1200mm)
Quotation will be provided within 12hours
15 years experience on PCB exporting
10% sales revenue invested in R&D and advanced automatic equipment from Japan, Taiwan and Germany every year
Product:Single Sided, Double Sided and Multilayer PCB, Rigid PCB,Flex PCB,Rigid-flex PCB,AL-base PCB.
| Material | CEM-3，FR-4(Normal to High Tg)，High CTI FR-4，PolyImide(PI) ，Aluminum Base，Rogers |
| Surface finish | HAL, HASL Leadfree, ENIG, Chem Tin, OSP, Gold Finger, Immersion Silver, ENEPIG |
| Min. Core thickness | 4mil/0.1mm |
| Prepreg type | 1080, 2116, 7628, 106, 3313, 2165, 1500. |
| Max board size | 24.41X47.24inch/620X1200mm |
| Copper thickness | Min. base copper 1/3Oz |
| Max. base copper 10Oz | |
| Min. board thickness | 2- Layer 0.2mm/8mil |
| 4-Layer 0.35mm/14mil | |
| 6-layer 0.65mm/26mil | |
| 8-Layer 1.0mm/40mil | |
| 10-Layer 1.3mm/51mil | |
| 12-Layer 1.6mm/63mil | |
| 14-Layer 1.8mm/71mil | |
| 16-Layer 2.0mm/79mil | |
| AOI (Automatic Optical Inspection) | Max.table size: 685X685mm |
| Max.inspect size: 620X620mm | |
| Max. thickness: 3.20mm(126mil) | |
| Min. thickness: 0.10mm(4mil)-core | |
| Min. width/gap: 3mil/3mil | |
| Board thickness Tolerance | ±0.10mm(4/6layers) |
| ±0.13mm(8/10layers) | |
| ±0.15mm(12/14/16layers) | |
| Max.board thickness | 6.0mm/236mil |
| Min.line width/space | 3/3mil |
| Min hole size | 4mil/0.1mm |
| PTH wall thickness | ≧25µm |
| Max. aspect ratio | 12:01 |
| PTH dia. Tolerance | ±0.075mm/3mil(Standard), ±0.05mm/2mil(Advanced) |
| NPTH dia. Tolerance | ±0.05mm/2mil(On laminate area) |
| ±0.03mm(On ground area) | |
| Hole location Tolerance | ±0.075(Standard) ±0.05mm(Advanced) |
| ±0.13(2nd drilled hole to 1st drilled hole location (mm) | |
| Slot size tolerance | ±0.075mm(board thickness≤1.0mm) |
| ±0.10mm (board thickness>1.00mm) | |
| V-CUT Remain thickness tolerance | ±0.10mm(Standard), ±0.076mm(Advanced) |
| Peelable mask Thickness | ≥8mil(0.2mm) |
| Insulation Resistance | >1012Ω |
| Through hole Resistance | <300Ω |
| Current breakdown | 10A |
| Peel Strength | 1.4N/mm |
| S/M Abrasion | >6H |
| Thermal stress | 288℃ 20Sec |
| Test Voltage | 20-300V |
| Min.blind/burried via | 4mil/0.1mm |
| Impedance control | (50Ω-100Ω)±10%(Standard)、(50Ω-100Ω)±7%(Advanced) |
We have 55 QC, FQC, QA specialists who utilize 100 testing devices, advanced techniques like IMDS and PPAP. Our products are tested in physics lab strictly before shipment on every part number. And report will be included in carton. All of our pcbs are RoHs/Reach/CE compliant.
Staffs in Quality department get traning once per week to be skilled and professional.
