Manufacturing Capability

Victory PCB Manufacturing Capability

Full range of PCB manufacturing and assembly services to fit all your printed circuit board capability needs.

Victory has introduced world-class PCB production equipment and high-precision testing equipment. We adopted a scientific management model to form a strong and leading process manufacturing capability.

  • 1 to 16 layers of PCB boards,

  • a minimum aperture of 0.1mm,

  • a minimum line width,

  • minimum trace width/space 0.075mm,

  • Line gap 0.075mm,

  • 0.4mm BGA Pitch

All are available in our processing. Victory can design and process special processes such as controlled depth milling, half hole, mixed pressure and so on.

ItemCapability
MaterialCEM-3，FR-4(Normal to High Tg)，High CTI FR-4，Polyimide(PI) ，Aluminum Base，Rogers
Surface finishHAL, HASL Leadfree, ENIG, Chem Tin, OSP, Gold Finger, Immersion Silver, ENEPIG
Min. Core thickness4mil/0.1mm
Prepreg type1080, 2116, 7628, 106, 3313, 2165, 1500.
Max board size24.41X47.24inch/620X1200mm
Copper thicknessMin. base copper 1/3Oz
Max. base copper 10Oz
Min. board thickness2- Layer 0.2mm/8mil
4-Layer 0.35mm/14mil
6-layer 0.65mm/26mil
8-Layer 1.0mm/40mil
10-Layer 1.3mm/51mil
12-Layer 1.6mm/63mil
14-Layer 1.8mm/71mil
16-Layer 2.0mm/79mil
AOI (Automatic Optical Inspection)Max.table size: 685X685mm
Max.inspect size: 620X620mm
Max. thickness: 3.20mm(126mil)
Min. thickness: 0.10mm(4mil)-core
Min. width/gap: 3mil/3mil
Design & Test3mil track width, 3mil tracks width/gap, IPC class 2/IPC class 3,Flying probe/tooling test, Differential impedance, TDR testing, Automatic optical inspection
Board thickness Tolerance±0.10mm(4/6layers)
±0.13mm(8/10layers)
±0.15mm(12/14/16layers)
Max.board thickness6.0mm/236mil
Min.line width/space3/3mil
Min hole size4mil/0.1mm
PTH wall thickness≧25µm
Max. aspect ratio12:01
PTH dia. Tolerance±0.075mm/3mil(Standard), ±0.05mm/2mil(Advanced)
NPTH dia. Tolerance±0.05mm/2mil (On laminate area)
±0.03mm (On ground area)
Hole location Tolerance±0.075 (Standard) ±0.05mm (Advanced)
±0.13 (2nd drilled hole to 1st drilled hole location (mm)
Slot size tolerance±0.075mm (board thickness≤1.0mm)
±0.10mm (board thickness>1.00mm)
V-CUT Remain thickness tolerance±0.10mm (Standard), ±0.076mm (Advanced)
Peelable mask Thickness≥8mil (0.2mm)
Insulation Resistance>1012Ω
Through hole Resistance<300Ω
Current breakdown10A
Peel Strength1.4N/mm
S/M Abrasion>6H
Thermal stress288℃ 20Sec
Test Voltage20-300V
Min.blind/burried via4mil/0.1mm
Impedance control(50Ω-100Ω) ± 10% (Standard)、(50Ω-100Ω) ± 7% (Advanced)
View More

PCB Delivery Lead Times

LayerArea<1㎡1㎡≦S<33㎡≦S<5㎡Fast
2L4day6day7day1day
4L6day7day8day2day
6L6day7day9day2day
8L7day9day9day3day
10L9day10day13day5day
Get Free Quote Now

Highest Standard and Certifications

We are certified to ISO9001 & 14001, IATF16949, SA08000, QC08000, ISO13485, UL certification. All surface mount boards go through a solder paste inspection machine and a 3D automated optical inspection machine for solder joints and part orientation. You can count on us to meet your needs, from the simplest boards to the most complex designs for small & medium scale production.
